| Product Number | EG-13.3-A-1609V1-QTCTP-A |
|---|---|
| Touch Panel P/N | EG-13.3-A-1609V1 |
| Display P/N | G133HAN01.1 |
| Screen Diagonal | 13.3/16:9 |
| Cover Outline Dimension | 324.1*207.8mm |
| Touch Panel View Area | 292.76*164.24mm |
| Touch Panel Active Area | 293.76*165.24mm |
| Touch Panel Thickness | 2.75mm |
| Display Outline Dimension | 309.7*184.1mm |
| Display Active Area | 293.472(H)x165.078(V)mm |
| Display Thickness | 9.6mm |
| Total Thickness | 12.85mm |
| Cover surface hardness | ≥7 |
| Ink adhesion | ≥4B |
| Impact resistance | ≥IK07 |
| Lamination to display | optical bonding |
| Touch Points | 10 points Typ. |
| Controller Interface | USB Typ. |
| Transmittance | >85% |
| Product Number | EG-13.3-A-1609V1-QTCTP-A |
|---|---|
| Touch Panel P/N | EG-13.3-A-1609V1 |
| Display P/N | G133HAN01.1 |
| Screen Diagonal | 13.3/16:9 |
| Cover Outline Dimension | 324.1*207.8mm |
| Touch Panel View Area | 292.76*164.24mm |
| Touch Panel Active Area | 293.76*165.24mm |
| Touch Panel Thickness | 2.75mm |
| Display Outline Dimension | 309.7*184.1mm |
| Display Active Area | 293.472(H)x165.078(V)mm |
| Display Thickness | 9.6mm |
| Total Thickness | 12.85mm |
| Cover surface hardness | ≥7 |
| Ink adhesion | ≥4B |
| Impact resistance | ≥IK07 |
| Lamination to display | optical bonding |
| Touch Points | 10 points Typ. |
| Controller Interface | USB Typ. |
| Transmittance | >85% |

Dongguan Ever Glory Photoelectric Co., Ltd., founded in 2011, is a high-tech enterprise with independent intellectual property rights. We operate 20,000㎡ production facilities located in Shenzhen and Dongguan. We specialize in providing high-quality 5″ to 75″ G+G and G+F capacitive touch panels, display solutions, and touch monitors and panel PCs. All production is completed in-house, with a dedicated cover glass production line, a Class-100 dust-free lamination workshop, and a monitor assembly line.
As a rapidly growing and innovative company, we were among the first in mainland China to initiate research and production of large-size PCAP technology, and we hold patents for lamination technology, equipment, and adhesives.
We are committed to being your one-stop touch solution partner. With over ten years of experience, we have developed extensive expertise across various applications, including industrial, outdoor, medical, banking, education, automotive, home automation,and entertainment sectors.



![]()

![]()

![]()

![]()

![]()




Standard packing with carton or wooden box
1.Our touch panel is safely sealed & packed with anti-static bag and foam wrapping.
2.Flexible packing options with carton or wooden box.
3. Shipping methods :DHL,UPS,FedEx,TNT,Air freight,LCL/FCL Sea freight.
