Self-Service Terminal
Self-service devices are widely used in public places such as banks, hospitals, and shopping malls. Touchscreens need to be highly durable, user-friendly, and vandal-resistant.
Features
1. High vandalism resistance: The touch screen has 6mm/8mm tempered glass design, reaching IK10 level of protection, ensuring the safety of the equipment in the public environment.
2. Privacy Protection: Optional anti-peep film is available to protect the user’s information security and privacy protection during use .
3. Support active pen input: support original handwriting input and write, effectively guarantee the authenticity of electronic signatures .
4. Strong anti-interference: In the condition of harsh operating environments, it can ensure the stable operation of the product .
Application Scenarios
IP65 IK10 Touch Displays for Self-Service Terminals
EverGlory supports outdoor self-service terminal touch displays for EV charging stations, payment kiosks, parking machines, vending systems, ticketing terminals and car wash equipment. A reliable outdoor HMI should combine sunlight readability, sealed front glass, PCAP wet touch, impact-resistant cover glass, protected connectors and a serviceable enclosure structure.
EV Charging Stations
High brightness, optical bonding, front IP65 protection, wet touch tuning and EMI review near charging electronics.
Outdoor Payment Terminals
Clear PCAP input, vandal-resistant glass options, payment module clearance and stable operation in rain or public-use conditions.
Car Wash and Kiosk HMI
Sealed flat front glass, chemical cleaning review, rear connector protection and wet glove operation by project.
| Requirement | Recommended Direction | Why It Matters |
|---|---|---|
| Outdoor readability | 700-1000+ nits, AG/AR glass and optical bonding by sunlight condition. | Prevents the screen from washing out under direct sun or reflective glass. |
| Water and dust protection | Front IP65 sealing with gasket, flat cover glass and connector protection. | Front sealing alone is not enough if cable exits and rear ports are exposed. |
| Impact resistance | Tempered cover glass, protected edge design and IK target review by project. | Public terminals need stronger front structure than indoor HMI panels. |
| PCAP touch stability | Wet touch, glove touch, grounding and EMI validation in the final enclosure. | Rain, payment electronics and charging modules can change touch behavior. |
Useful Engineering Guides
RFQ Details to Send
- Terminal type and enclosure drawing
- Screen size, brightness and installation angle
- IP/IK target, touch condition and glass requirement
- Payment module location, interface and service access
