12.1-inch Outdoor Touch Monitor

Our 12.1-inch outdoor touch monitor is sunlight-readable | IP65 Front | PCAP Touch for Kiosks, EV Chargers & Wayfinding

Meta description (≤160): 12.1″ outdoor touch monitor with 1000–1500 nits, IP65 front, optical bonding, -20–70 °C, glove/wet touch. Built for kiosks and EV charging.

Built for the outdoors

This 12.1-inch outdoor touch monitor stays clear in full sun and works in the rain. It pairs 1000–1500 nits with optical bonding and anti-glare glass. As a result, text and maps stay readable at noon. In addition, the IP65 front bezel blocks dust and water. Therefore, you can mount it in open-air kiosks, EV chargers, ticket machines, and wayfinding totems.

Why it performs better

• High brightness: 1000–1500 nits keeps content visible in daylight.

• Low glare: Optical bonding cuts reflections; AR glass reduces glare even more.

• Weather ready: IP65 front seals against dust and water jets.

• Durable glass: 3–4 mm tempered cover, optional IK07.

• Wide temps: -20 to 70 °C for summer heat and winter cold.

• Reliable touch: 10-point PCAP supports wet hands and common gloves.

• Compliant: CE/FCC/RoHS for public installs.

Easy to integrate

First, connect your player or IPC by HDMI or VGA (DP optional). Next, plug USB-HID for touch—no driver on Windows or most Linux. Finally, power it with 12–24 V DC.

• Mounting: Panel mount or VESA 75×75.

• Stable supply: Long-life panel plan and controlled BOM for rollouts.

• Power options: Lockable power connector on request.

Key specs

Use cases

• EV charging HMI and parking kiosks.

• QSR self-order, vending, parcel lockers.

• Transit and city wayfinding.

• Factory dashboards and vehicle terminals.

Installation & service

To start, use the panel kit and the cutout drawing. Then connect video and USB. After that, power up and run the touch test tool. In case of harsh coastal or alpine sites, add conformal coating or a heater kit. Moreover, field-replaceable power modules and cables reduce downtime.

Documentation & trust (E-E-A-T)

You get a full datasheet, 3D STEP, panel cutout, and wiring diagrams. In addition, we provide burn-in and thermal data upon request. For fleet projects, we keep batch records and retention samples.

Custom options

• Logo print on glass or bezel.

• High-TNI TFT for direct sun.

• Privacy or extra AR coatings.

• DP input, lockable power, cable kits.

• All-in-one panel PC (Intel®/ARM) with sealed front.

FAQs

Does it handle strong sun?
Yes. High brightness plus bonding and AR glass keep screens readable. Even so, use a ventilated enclosure in peak summer.

Will touch work in rain or with gloves?
Yes. The PCAP controller supports light rain and common gloves. We can also tune sensitivity.

What if I only have DisplayPort?
Choose the DP option or use a DP-to-HDMI adapter.

Can you supply a panel PC?
Yes. The same front module can pair with an SBC for a sealed HMI.
