32 Inch Industrial Touch Screen Monitor for Large HMI Displays
A 32 inch industrial touch screen monitor for large HMI displays, production-line dashboards, kiosk systems and equipment integration. The YW02 standard model combines Full HD display, PCAP touch, HDMI/VGA input and AC 220 V power.
This standard YW02 product page is intended for large HMI displays, production-line dashboards, kiosk systems and equipment integration. It is positioned separately from outdoor high-brightness, IP-rated waterproof and panel PC product pages.
Key Features
- 32 inch Full HD industrial touch screen monitor for large HMI.
- PCAP capacitive touch with USB drive-free controller.
- HDMI + VGA input for industrial PC and controller integration.
- AC 220 V input and 60 W max power from the local spec.
- Suitable for production dashboards, large kiosks and machine control stations.
Technical Specifications
| Model | YL-GZYW02Q320TC-V1 |
|---|---|
| Display size | 32 inch |
| Resolution | 1920 x 1080 |
| Brightness | 250 cd/m2 |
| Contrast ratio | 1000:1 |
| Viewing angle | 89/89/89/89 |
| Touch type | Capacitive touch screen |
| Touch interface | USB, drive-free |
| Touch response | <=5 ms |
| Surface hardness | Mohs 7 |
| Signal input | HDMI + VGA |
| Power connector | AC 220 V |
| Max power | 60 W |
| Operating temperature | 0 C to 50 C |
| Storage temperature | -20 C to 60 C |
| Dimension | Confirm before publishing exact outer dimension |
| Mounting | VESA 100 x 100 mm |
Typical Applications
Typical use cases include industrial HMI, kiosk systems, control cabinets, automation equipment, inspection and testing equipment, commercial terminals and OEM machine interfaces.
Customization Options
EverGlory can support project-based customization for cover glass, surface treatment, touch tuning, cable length, brightness, interface, mounting structure and product appearance. Share your installation space, controller interface, brightness requirement, operating environment and estimated quantity for evaluation.
Related Product Options
- Standard industrial touchscreen monitor series
- Touch screen monitor category
- Outdoor high brightness touchscreen monitor
- Embedded industrial touchscreen monitor selection guide
FAQ
Should another 32 inch product page be created?
No. Product ID 3824 already exists and is updated instead of creating a duplicate.
What should the 32 inch page emphasize?
It emphasizes large-format HMI, production dashboards, kiosk systems and OEM integration, not IP67 waterproof or outdoor high-brightness positioning.
Request a Quote
Send your size, mounting drawing, interface, brightness, touch requirements, operating environment and order quantity to EverGlory for a custom industrial touch monitor quote.
32 Inch Industrial Touch Screen Monitor for Large HMI Displays Engineering Information
32 Inch Industrial Touch Screen Monitor for Large HMI Displays is a 32 inch industrial touch screen monitor for embedded display, OEM equipment, kiosk and HMI integration. It should be reviewed with LCD model, touch interface, video input, backlight, bonding and mechanical mounting so Ever Glory can confirm integration risk before sampling or quotation.
- Product Category
- Touch Screen Monitor
- Product Role
- industrial touch screen monitor
- Size / Format
- 32 inch
- Best Fit
- embedded display, OEM equipment, kiosk and HMI integration
- Review Focus
- LCD model, touch interface, video input, backlight, bonding and mechanical mounting
- Customization
- Cover glass, touch tuning, mounting structure, interface configuration, branding, bonding and enclosure fit
Information Needed for Review
- Mechanical drawing, target installation space and 32 inch display or housing requirement.
- LCD model, touch interface, video input, backlight, bonding and mechanical mounting.
- Operating environment, brightness, temperature, IP rating, vibration, cleaning or glove-touch expectations.
- Target quantity, certification needs, cable direction, connector position and production schedule.
Typical Applications
OEM equipment, kiosks, self-service terminals, medical devices, POS systems and industrial control interfaces.
Suitable for projects that need stronger enclosure design, stable touch performance and long-term field reliability.
This page is positioned under Touch Screen Monitor, helping buyers compare related Ever Glory products with clearer engineering context.
Common Engineering Questions
Is this industrial touch screen monitor ready for direct installation?
It depends on the final enclosure, interface, power, mounting and software environment. Ever Glory reviews the drawings and application before confirming a production-ready solution.
What information helps confirm feasibility faster?
Send LCD model, touch interface, video input, backlight, bonding and mechanical mounting, mechanical drawings, operating environment, target quantity and any branding or certification requirements.
Can Ever Glory customize this product?
Yes. Common customization includes cover glass, touch controller tuning, bonding, brightness, interface, housing, cable direction, logo printing and mounting structure.
For an accurate quotation, send drawings and application details instead of only screen size.
